Self-powered system provides cost-savings and freedom of placement within facility
Low 9.5” step-on height for easy accessibility
Constant Rate of Acceleration and our patented suspension design delivers a perpetually smooth motion free of wheels and tracks
LED console display is easily navigated by users of all experience levels
Contralateral action with tapered, dual action handlebars mimics the body’s true movement and proper fit
Removable disk for easy serviceability
Ergo Form™ Grips with integrated resistance controls enhances comfort and accessibility to key functions
53.3 cm / 21" stride length accommodates all users for a comfortable, efficient, and natural workout
Key Features
Self-powered System: Our maintenance-free drive is completely self-powered and cord-free, providing cost-savings and freedom of placement within the facility.
Removable Disk: All Matrix Ascent Trainers & Suspension Ellipticals feature a removable disk for quick access and easy serviceability.
Constant Rate of Acceleration: Constant Rate of Acceleration and our patented suspension design delivers a perpetually smooth motion free of wheels and tracks.
Contoured Handle Bars: The tapered, dual-action handlebars provide a total-body workout that strengthens core muscles. The contoured handle design accommodates a wide range of user sizes for a more comfortable workout.
CONSOLE
Display Type: Alphanumeric LED with profile display
Display Feedback: Time, distance (kilometers or miles), calories, calories per hour, level, speed, RPM, heart rate, METs, Watts, Profile
Languages Available: English, German, French, Italian, Spanish, Dutch, Portuguese, Swedish, Finnish
Resistance Range: 1-25
Workouts: Manual, rolling hills, target HR, interval training, constant watts, fat burn, random, fitness test
CSAFE Ready-FitLinxx Certified: Yes
Netpulse Compatible: Yes
IPTV Compatible: No
On-The-Fly Program Change: Yes
One-Button Start: No
Integrated Vista Clear Television Technology: No
FITCONNEXION Ready: Yes
WiFi: No
Nike + iPod Compatible: No
Personal Fan: No
USB Port: Yes
Virtual Active Compatible: No
Asset Management Compatible: No
mPower Workout Training and Fitness Network Compatible: No
Pause Function: Yes
Bottle Holder: Yes
Reading Rack: No
FEATURES
Stride Length: 53.3 cm / 21"
Contact & Telemetric HR: Yes
Footpad Insert: No
Pedal Spacing: 6.4 cm / 2.5"
Handlebar Design: Multi-position dual action / Custom ergo-bend stationary
Remote Buttons: Yes
Resistance System: Brushless Generator
TECH SPECS
Power Requirements: Self-Powered - Powered 100v-240v - 50/60Hz AC
Minimum Watts: 5 Powered / 21 Self-Powered
Minimum RPM: 10 Powered / 25 Self-Powered
Assembled Dimensions: 178 x 74 x 174cm / 70" x 29.2" x 68.5"
Max User Weight: 182 kg / 400 lbs
Assembled Weight: 181.2 kg / 398 lbs
Shipping Weight: 193.5 kg / 425 lbs
