Handlebars: Over-molded handlebar design offers the user three comfortable riding positions: upright, cruising and road. In the road position, the ergonomic-shaped handlebars position the wrists in a natural, neutral position. The wide width of the handlebars provides stability and comfort along the entire forearm. The overall width of the handlebars is similar to indoor cycling bikes, which is narrower than most stationary bikes. This places the user in better ergonomic position, with the forearms more directly under the shoulders. In the cruising position, the wide handlebar is more comfortable on the user's hands. Touch heart rate is integrated in the upright and road-race positions.
Seat: Improved, ergonomic saddle design with comfort groove is injection-molded polyurethan with custom density for optimum riding comfort. 10.5 inches (27 cm) width quickly tapers to a narrow nose for improved riding comfort.
Biomechanics: To achieve proper pedaling biomechanics, the seat post angle and seat post offset from the crank are key to efficient pedaling and reduced shear force on the knee. The seat post angle is 74 degrees with a 5-inch (13 cm) offset from the crank axle. This places the forward knee directly over the ball of the foot (or pedal spindle) when the pedals are in a horizontal position.
Bearings: The bottom bracket assembly uses a hardened steel shaft with deep-groove sealed precision ball bearings designed for smooth operation and exceptional service life.
Pedals: For double the convenience, dual-sided pedals allow the rider to use the pedals with or without the integrated pedal strap. The extra wide pedal comfortably accommodates feet of all sizes, which allows proper pedaling form with the foot directly over the user's knee.
Frame: Two-step powder-coating process applies rust-resistant undercoat and cosmetic topcoat to steel frame.
Seat Adjustment: New, convenient seat adjustment allows the user to easily change the seat to their desired height, either on or off the bike.
Covers: Covers are attached with minimal hardware and can be removed without taking off the pedals or cranks.
Transport Wheels: Integrated
Cable Management: Optional
Universal Seat Mount: Yes
3-Piece Crank: 3-piece crank tightens positively, reducing the need for periodic adjustments. The 170 mm crank arm accepts any standard road or mountain bike pedal.
Drive System: The two-stage drive system yields a smooth, comfortable, quiet operation with a lower start-up resistance and consistent resistance progression.
3-Phase Generator: 3-phase generator / eddy current resistance system requires no backup battery in order to efficiently power the bike.
Belt Drive: Belt drive for smoother, quieter operation and reduced maintenance.
Resistance Levels: 25
Minimum Watts: 18 watts (level 1 at 20 RPM)
Maximum Watts: 750 watts (level 25 at 150 RPM)
Console Type: P10 stream-lined LED display
Tap Control: No
Tactile Dome Keys: Yes
QuickStart: Yes
Motion Controls: No
Numeric Keypad: Yes
Units Selection: Metric or U.S. Standard
Preset Programs: 6 programs accessed directly by 6 buttons: Manual, Interval, Basic Heart Rate Control, Weight Loss, Random, Hill Climb
Console Language(s): English, Dutch, German, Spanish, French, Portuguese, Italian, Romanized Russian
Maximum Pause Time (Pause): 30 seconds
Electronic Readouts: Calories, Distance, Speed, Watts, Heart rate, Profile, SmartRate®, Resistance, RPM, Time, Percent complete, Heart rate
Maximum Workout Time: unlimited
Touch: Yes.
Telemetry: Yes. Integrated telemetry heart rate reads heart rate from a user's heart rate chest strap.
SmartRate: No
Reading Rack: Integrated
Personal Viewing Screen (PVS) (Specification): 15in. Screen
Personal Viewing System (PVS) + Personal Entertainment Player (PEP) (iPod® compatibility): Optional
Entertainment Cap / Wireless Receiver: Optional
CSAFE Ready: Yes
FitLinxx Compatible: No
Diagnostics: Ability to set club parameters, e.g. limit exercise time, set default language and pause time.
Maximum User Weight (lbs / kg): 350 lbs / 159 kg
User Height Range (inches / cm): 58 to 78 / 147 to 198
Crank Width: 19 / 7.5
Length: 48 inches / 122 cm
Width: 21 inches / 53 cm
Height: 57 inches / 146 cm
Height with PVS: 70 inches / 178 cm
Equipment Weight: 160 lbs / 73 kg
